Key attributes
Measurement System:Metric
material:Q235B, Q235
capacity:Standard
Other attributes
place of origin:Hebei, China
color:Silver, Grey
brand name:ANKA
model number:Ground screw
Product name:Ground screw
Diameter:76mm
Installation Site:Open Field
Surface finished:Galvanizde
Material:Q235, Q235B
Length:1200mm/1600mm/1800mm/customized
Thickness:2.75mm/3mm/3.5mm
Zinc Thickness:> 80 μm
Temperature Range:-50C°to 60C°
Warranty:10 Years
Packaging and delivery
Selling units:Single item
Single package size:5X5X2 cm
Single gross weight:0.030 kg
China stainless steel hardware anchor galvanized ground spiral screw foundation for solar mounting system Products
Product Name | Ground Screw |
Installation Site | Open Field/ Ground |
Material | Q235 |
Surface | Hot Dip Galvanization |
Thickness | 2.75mm/3mm/3.5mm |
Length | 1200mm/1600mm/1800mm/customized |
Temperature Range | -50C°to 60C° |
Series | Flange Top, Tube Top |
Standard | AS/NZS 1170; SGS;ISO |
Warranty | 10 Years |
Application | 1)Timber Construction; 2) Solar Power Systems; 3) City and Parks; 4) Fencing Systems; 5) Road and Traffic; 6) Sheds andContainers; 7)Flag Poles and Marks; 8)Garden and Leisure; 9)Boards and Banners; 10)Event Structures. |
Service | OEM; We Offer Professional Customization Services. Our Engineers Will Design the Most Suitable Solar Mounting Structure Solution Based on Local Geology, Snow Load and Wind Speed. |
Recommend Products
Lead time
Quantity (pieces) | 1 – 10000 | > 10000 |
Lead time (days) | 15 | To be negotiated |
